Product Documentation

Document	Pages	Notes
Brochure	2

Product

Parameter	Value	Description
Shape	Rectangular
Height	2382 mm	The vertical distance between the top and bottom surfaces of an item that is placed in its conventional orientation.
Width	1134 mm	The horizontal distance between the left and right surfaces of an item that is placed in its conventional orientation.
Depth	30 mm	The horizontal distance between the front and rear surfaces of an item that is placed in its conventional orientation.
Area	2.701188 m²
Weight	33.7 kg	The weight of the item.
Wind Load	2400 Pa max
Snow Load	5400 Pa max

Cell

Parameter	Value	Description
Count	132
Type	Mono Si	The cells are made of Monocrystalline Silicon.
Attribute	Bifacial

Power

Parameter	Value	Description
Rated Power at STC	610 W	Output Power at Maximum Power Point under Standard Test Conditions
Power Density at STC	225.827 W/m²	Power Density under Standard Test Conditions
Efficiency at STC	22.6 %	Module Efficiency under Standard Test Conditions
Degradation Rate	0.4 %/yr	The rate at which the solar panel's power output decreases over time as the panel ages.

Current

Parameter	Value	Description
System Fuse Rating	30 A max

Junction Box

Parameter	Value	Description
Solid Ingress Protection Level	IP6x	The product is dust-tight.
Liquid Ingress Protection Level	IPx8	The product is protected against the effects of continuous immersion in water.

Positive Lead

Parameter	Value	Description
Wire Diameter	12 AWG (4 mm²)
