Product
| Parameter | Value | Description |
|---|---|---|
| Operating Frequency | 460 to 470 MHz | |
| Type | Handheld | |
| Center Frequency | 465 MHz | |
| Bandwidth | 10 MHz | The frequency range occupied by a modulated carrier. |
| Length | 2.5 in | |
| Personal Band | GMRS | General Mobile Radio Service (462.550 - 467.725 MHz) |
| Land Mobile Band | UHF | Land mobile UHF band (450 - 470 MHz) |
Signal Propagation
| Parameter | Value | Description |
|---|---|---|
| Power | 50 W max | The input power limit of an antenna. |
| Gain | 3 dBd | The ability of an antenna to radiate RF energy in a specific direction. |
| ERP | 99.763 W max | Effective Radiated Power |
Feedpoint
| Parameter | Value | Description |
|---|---|---|
| Connector Types | BNC-Male | BNC Male |
| SMA-Female | SMA Female | |
| SMA-Male | SMA Male | |
| TNC-Male | TNC Male | |
| UHF-Male | UHF Male (PL-259) | |
| Impedance | 50 Ω | The effective resistance of an antenna to alternating current at a specific frequency due to the combined effects of ohmic resistance, inductance, and capacitance. |
