Product Documentation
| Document | Pages | Notes |
|---|---|---|
| T2 - FCC Test Results |
Product
| Parameter | Value | Description |
|---|---|---|
| Type | Transceiver | The radio can receive and transmit signals. |
| Width | 1.88 in | The distance between the left and right surfaces of the main body of the radio, excluding protrusions. |
| Height | 6.378 in | The distance between the top and bottom surfaces of the main body of the radio, excluding protrusions. |
| Depth | 0.91 in | The distance between the front and rear surfaces of the main body of the radio, excluding protrusions. |
| Weight | 0.255 kg | The mass of the main body of the radio, including the removable battery or removable front panel. |
Tuning System
| Parameter | Value | Description |
|---|---|---|
| Scan Type | Channel | The radio's tuning system can scan some or all of the channels programmed into its memory. |
| Repeater Capable | No | Memory channels can have different transmit and receive frequencies, facilitating the use of radio repeaters. |
Signaling System
| Parameter | Value | Description |
|---|---|---|
| CTCSS Tones | 38 max | The number of distinct CTCSS tones supported by the radio. |
| DCS Codes | 83 max | The number of distinct DCS codes supported by the radio. |
| Roger Beep | Yes | Indicates that a transmitter is capable of emitting a short beep at the end of each transmission. |
Receiver
| Parameter | Value | Description |
|---|---|---|
| Personal Bands | FRS | Family Radio Service (462.550 - 467.7125 MHz) |
| GMRS | General Mobile Radio Service (462.550 - 467.725 MHz) | |
| Broadcast Band | WX | NOAA weather broadcast band (162.400 - 162.550 MHz) |
| Weather Alerts | Yes | The radio provides severe weather alerts and other S.A.M.E. localized programming. |
Transmitter
| Parameter | Value | Description |
|---|---|---|
| Personal Band | GMRS | General Mobile Radio Service (462.550 - 467.725 MHz) |
| Output Power | 2 W max | The maximum RF power that a transmitter can produce, as reported by the manufacturer in product documentation. |
| Measured Power | 1.589 W max | Actual output power measured by a telecommunication certification body (TCB) and reported to the Federal Communications Commission. |
| VOX | Yes |
Keypad
| Parameter | Value | Description |
|---|---|---|
| Lockable | Yes | The keypad can be configured in a way that disables the function of most keys. |
| Audible | Yes | The keypad can be configured to emit a sound each time that a key is pressed. |
Display
| Parameter | Value | Description |
|---|---|---|
| Type | LCD | Liquid Crystal Display with Fluorescent Backlighting |
Battery
| Parameter | Value | Description |
|---|---|---|
| Charge Capacity | 1100 mAh | The amount of charge stored in a fully-charged battery. |
| Type | Li-Poly | Lithium Polymer |
| Charging Method | USB-C |
Bonus Features
| Parameter | Value | Description |
|---|---|---|
| LED Flashlight | Yes | The radio contains an LED that can be switched on to provide a small amount of task lighting. |
