Product

Parameter	Value	Description
Type	Transceiver	The radio can receive and transmit signals.
Width	2.25 in	The distance between the left and right surfaces of the main body of the radio, excluding protrusions.
Height	5 in	The distance between the top and bottom surfaces of the main body of the radio, excluding protrusions.
Depth	1.5 in	The distance between the front and rear surfaces of the main body of the radio, excluding protrusions.
Weight	258 g	The mass of the main body of the radio, including the removable battery or removable front panel.

Receiver

Parameter	Value	Description
Personal Bands	FRS	Family Radio Service (462.550 - 467.7125 MHz)
	GMRS	General Mobile Radio Service (462.550 - 467.725 MHz)

Transmitter

Parameter	Value	Description
Personal Band	GMRS	General Mobile Radio Service (462.550 - 467.725 MHz)
Output Power	3 W max	The maximum RF power that a transmitter can produce, as reported by the manufacturer in product documentation.
Measured Power	2.94 W max	Actual output power measured by a telecommunication certification body (TCB) and reported to the Federal Communications Commission.

Battery

Parameter	Value	Description
Charge Capacity	2200 mAh	The amount of charge stored in a fully-charged battery.
Energy Capacity	16.28 Wh	The amount of energy stored in a fully-charged battery.
Type	Li-Ion	Lithium Ferrous Phosphate (LiFePO4)
Voltage	7.4 V	The nominal voltage of a battery.
Removable	Yes	Battery is removable, allowing a discharged battery to be quickly replaced with a fresh one.
Charging Method	Drop-In
